http://www.kraususa.com/kbu24-32-inch-u ... -sink.html


Click the installation tab and a downloadable .dxf is there labeled cut out template.

http://www.scandvik.com/index.cfm/metho ... s/id/4.htm

Stainless sinks for boats.

Are looking to to bevel the bottom edge of your because you are running open tooling? If that is the case, set up the beveling tool as a profiling tool and add it to your profiling kit. You will need to adjust the height on the control to your desired level of bevel. Profiling kits in Easystone all ...

Text in EasyStone needs to exploded to separate the geometries.

I can look into my software in the morning and see how to do it. I couldn't tell you off the top of my head.
But, what machine do you have? Is the blade on a gearbox or direct mounted to a cone? 4 axis or 5? Inquiring minds need to know.

I have had very good luck using ADI's MFP5 oscillating to reduce linear lines. You need to keep your tools dressed and maintained for best results. You want therm to take off as little as possible.

It is about .004 to .006 of an inch between ripples in your stone and a nice polish. Set them up light and run them in a few hundred feet, then re-adjust. Unlike a Magic/Clay wheel, you will want these to hit as light as possible but touch the whole profile.

http://vimeo.com/83696554


I think maybe.

(not to sure how to embed videos from Vimeo)

In the other thread you started about this someone mentioned that some of these machines use Stonevision/Alphacam to generate the oscillation or the Fanuc control does it. Which one is this machine trying to use?

nevermind.

Formax is a new 5 axis saw from CMS. Offered w/ a Jet head or with out. That is ALL I know about it.

photo (12).JPG ADI DemiBull Metals 1-4 for sale BEST OFFER!!!!!! These are the older slower speed one w/ no bottom rolls. Decent shape, been in my toolbox for way too long. Make me an Offer, Get creative. I just need them to find them a new home that loves them. Justin.Qualey@gmail.com or 207-951-3...

What are the specific problems with the cut? If the c axis is not set dead perpendicular, the blade will drag. Is the kerf wider and blade paint wearing unevenly? A out of whack C would not make cuts that have a bow in them I don't think, however play in it (is it antibacklash?) or the overall rigi...

41,569 in the continental US.

Sometimes the keys get an electronic charge and they get fried. Alphacam will sell you a new key, but they will also tell you that this is the reason for their mateinence program. If you are on their program, keys are free.

Google Translate says

Irregular timing master
Overload cycle master

5000 rpm is way to fast for 2 imp. Try 2200 at 2 imp. The 5k is glazing your bits.

Hit your tool release button and hit the cone with a dead blow mallet. If you machine something hard, sometimes the excess force can jam your tool in the spindle. Make sure to hit it and then spin before you hit it again.

Check the Actual Voltage going to your machine. Spikes or Drops in voltage is usually the culprit when you start frying things in your cabinet.

they took off the spindle speed knob after your vintage and before mine. Too many people destroyed tools with that knob. it can be dangerous. The function is still there, but it is kinda hidden in the Fanuc Keys that no one seems to ever use.

below the jog key on the Fanuc's you will see 2 keys with a + and a - on them. These will drop your spindle speed while working.

Tank wrote:, apparently a majority of Americans don't care about freedom or liberty,

My wife is happy she is free manage her vagina as she pleases.

Bubbles only has eyes for cats.

clhilde wrote:Want a partner?

You would fit in well with Julian, Ricky and Bubbles.
